The Megger DLRO10HD ohmmeter combines ultimate simplicity of operation with a rugged IP65 case and is designed for stable ground and bench operation. The unit is powered from either its rechargeable battery or line power making it suitable for continuous testing in production line/repetitive use environments. Rotary switch controls are simple and easy to operate in all weather conditions and with gloved hands. A large, clear, backlit LCD display is easy to read from a distance.
Features:
• Accuracy ±0.2% ±20 mΩ
• Battery Type 6 V, 7Ah sealed lead acid
• 90 – 264 V, 50-60 Hz
• Weight 6.7 kg
• Safety rating In accordance with IEC61010-1, CATIII 300 V when used with DH7 leads
• Maximum lead resistance 100 mΩ total for 10 A operation irrespective of battery condition.
